US TRENCH GRATES

Experience the fusion of robust utility and refined style with Jonite's ADA-compliant trench grates, tailored for the discerning US market. These durable, visually appealing grates ensure efficient drainage while enhancing your space's aesthetic. Trust Jonite trench grates for a perfect blend of function and elegance in modern exteriors.

Pebbles 3"

Load Class 6KN

Suitable Channels NDS Mini Channels

ADA Yes

Dimensions 3”W x 24”L x 0.98”T

Interlace 3"

Load Class A15

Suitable Channels NDS Mini Channels

NDS Mini Channels Yes

Dimensions 3”W x 24”L x 0.98”T

Pebbles 5"

Load Class 6KN

Suitable Channels ACO, ULMA, MEA

ADA Yes

Dimensions 5”W x 19.69”L x 0.75”T

Chiseled 5"

Load Class A15

Suitable Channels ACO, ULMA, MEA

ADA Yes

Dimensions 5”W x 19.69”L x 0.87”T

Cross-Stitch 5"

Load Class A15

Suitable Channels ACO, ULMA, MEA

ADA Yes

Dimensions 5”W x 19.69”L x 0.75”T

Keyholes 5"

Load Class A15

Suitable Channels ACO, ULMA, MEA

ADA Yes

Dimensions 5”W x 19.69”L x 0.87”T

Interlace 5"

Load Class A15

Suitable Channels ACO, ULMA, MEA

ADA Yes

Dimensions 5”W x 19.69”L x 0.87”T

Palm 5"

Load Class A15

Suitable Channels ACO, ULMA, MEA

ADA Yes

Dimensions 5”W x 19.69”L x 0.87”T

Square Slots 5"

Load Class A15

Suitable Channels ACO, ULMA, MEA

ADA Yes

Dimensions 5”W x 19.69”L x 0.75”T

Pebbles 11.8"

Load Class 6KN

Suitable Channels Concrete

ADA Yes

Dimensions 11.8”W x 19.69”L x 1.38”T

Chiseled 11.8"

Load Class 6KN

Suitable Channels Concrete

ADA Yes

Dimensions 11.8”W x 19.69”L x 0.98”T

Cross-Stitch 11.8"

Load Class 6KN

Suitable Channels Concrete

ADA Yes

Dimensions 11.8”W x 19.69”L x 0.98”T

Keyholes 11.8"

Load Class 6KN

Suitable Channels Concrete

ADA ADA

Dimensions 11.8”W x 19.69”L x 1.1”T

Interlace 11.8"

Load Class 6KN

Suitable Channels Concrete

ADA Yes

Dimensions 11.8”W x 19.69”L x 0.98”T

Palm 11.8"

Load Class 5KN

Suitable Channels Concrete

ADA Yes

Dimensions 11.8”W x 19.69”L x 1.1”T

Square Slots 11.8"

Load Class A15

Suitable Channels Concrete

ADA Yes

Dimensions 11.8”W x 19.69”L x 0.98”T

Slotted 8.3"

Load Class A15

Suitable Channels Concrete

ADA Yes

Dimensions 8.3”W x 19.69”L x 0.98”T

Slotted 11.5"

Load Class A15

Suitable Channels Concrete

ADA Yes

Dimensions 11.5”W x 19.69”L x 0.98”T

Slotted 14"

Load Class A15

Suitable Channels Concrete

ADA Yes

Dimensions 14”W x 19.69”L x 0.98”T

Slotted 17"

Load Class A15

Suitable Channels Concrete

Concrete Yes

Dimensions 17”W x 19.69”L x 1.38”T

Slotted 19.7"

Load Class A15

Suitable Channels Concrete

ADA Yes

Dimensions 19.7”W x 14.37”L x 1.38”T

Traffic Square Slots 5"

Load Class B125

Suitable Channels ACO, ULMA, MEA

ADA Yes

Dimensions 5”W x 19.69”L x 1.38”T

Traffic Slotted Round Slots 8.3"

Load Class B125

Suitable Channels Concrete

ADA Yes

Dimensions 8.3”W x 19.69”L x 1.38”T

Traffic Slotted Round Slots 11.5"

Load Class B125

Suitable Channels Concrete

ADA Yes

Dimensions 11.5”W x 19.69”L x 1.38”T

Traffic Slotted Round Slots 14"

Load Class B125

Suitable Channels Concrete

ADA Yes

Dimensions 14”W x 19.69”L x 1.38”T

Traffic Slotted Round Slots 17"

Load Class B125

Suitable Channels Concrete

ADA Yes

Dimensions 17”W x 16.54”L x 1.97”T

Slotted 8.3" Corner

Load Class A15

Suitable Channels Concrete

ADA Yes

Dimensions 8.3”W x 19.69”L x 0.98”T

Slotted 11.5" Corner

Load Class A15

Suitable Channels Concrete

ADA Yes

Dimensions 13.46” x 13.46” 0.98”T

Slotted 14" Corner

Load Class A15

Suitable Channels Concrete

ADA Yes

Dimensions 15.94” x 15.94” x 0.98”T

Slotted 17" Corner

Load Class A15

Suitable Channels Concrete

ADA Yes

Dimensions 19.09” x 19.09” x 1.38”T

Slotted 19.7" Corner

Load Class A15

Suitable Channels Concrete

ADA Yes

Dimensions 19.7”W x 14.37”L x 1.38”T

Traffic Slotted Square Slots 5" Corner

Load Class B125

Suitable Channels Concrete

ADA Yes

Dimensions 6.69” x 6.69” x 0.98”T

Traffic Slotted Round Slots 8.3" Corner

Load Class B125

Suitable Channels Concrete

ADA Yes

Dimensions 10.24” x 10.24” x 1.38”T

Traffic Slotted Round Slots 11.5" Corner

Load Class B125

Suitable Channels Concrete

ADA Yes

Dimensions 13.46” x 13.46” 1.38”T

Traffic Slotted Round Slots 14" Corner

Load Class Load Class

Suitable Channels Concrete

ADA Yes

Dimensions 15.94” x 15.94” x 1.38”T
